Southwire MC-PCS Duo power and control/signal cable 250-Feet 12 / 4 Stranded Aluminum MC (Metal Clad) Cable
$567.50
- Series Name: MC-PCS Duo power and control/signal cable
- Type: MC cable
- Cable Length (Feet): 250
-
Free shipping -
Estimated Delivery: 5-10 days -
Pickup not available
Southwire MC-PCS Duo power and control/signal cable 250-Feet 12 / 4 Stranded Aluminum MC (Metal Clad) Cable
Southwire’s MC-PCS Duo is suitable for use as circuits for branch power distribution in commercial, industrial, institutional and multi-residential buildings as well as power, lighting, control and signal circuits. It works with LED lighting with 0-10V dimming. This cable is constructed with 12 AWG CU type THHN/THWN power and ground conductors along with a control conductor assembly composed of a 30 mil PVC jacket covering two 16 AWG CU type TFN control conductors. The phase conductors, ground and control conductor assembly are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the taped assembly. Yellow stripe/blocks are printed on the outside of the armor and the print legend is applied in black print on every 4th yellow stripe/block.
Highlights
- LED lighting with 0-10V dimming
- Full compliance with NEC 330, NEC 725, and UL 1569
- Cable reverse wound on reel for ease of pulling and installation
- Lightweight aluminum interlocked armor
- Power, lighting, control and signal circuits
Specifications
| General | |||
|---|---|---|---|
| Series Name | MC-PCS Duo power and control/signal cable | Type | MC cable |
| Sub-Brand | N/A | ||
| Dimensions | |||
|---|---|---|---|
| Cable Length (Feet) | 250 | ||
| Features | |||
|---|---|---|---|
| Armor Material | Aluminum | Number of Conductors | 4 |
| Commercial/Residential | Commercial | Number of Strands | 1 |
| Conductor Material | Aluminum | RoHs Compliant | Yes |
| Direct Burial | No | Shielded | No |
| Fire Resistant | No | Stranded or Solid | Stranded |
| Ground Wire | Green insulated copper | UV Resistant | No |
| Maximum Amperage | 25 | Voltage Rating | 600 |
| Moisture Resistant | No | Wire Gauge | 12 |
| Compatibility | |||
|---|---|---|---|
| Conduit Compatible | No | ||
| Certifications | |||
|---|---|---|---|
| CA Residents: Prop 65 Warning(s) | Safety Listing | UL safety listing | |
| Miscellaneous | |||
|---|---|---|---|
| UNSPSC | 26121500 | ||
| Brand | Southwire |
|---|
