ECHO 25.4 cc Gas String Trimmer

ECHO SRM-2620T 25.4 cc Gas 2-Stroke X Series Straight Shaft String Trimmer

As part of ECHO’s X Series Collection, the SRM-2620T lawn trimmer redefines the performance standards for professional landscapers. It offers a revolutionary combination of low weight and high horsepower. The Pro Torque gear case featured in this weed trimmer provides 27% more torque for powering through dense ground cover. All ECHO yard trimmer engines are certified with the highest EPA engine durability rating.

• For questions about service and repair, please call Echo at 1-800-432-ECHO or reference the Service & Repair document
• Use a 50:1 ratio of fuel to oil mix for 2-stroke cycle engines, recommend using only fresh gas with a minimum octane rating of 89 or higher (mid-grade to premium) at all times
• 50:1 ratio equal 1 US Gal. 89 octane plus 2.6 fl. oz. ECHO PowerBlend gold oil or ECHO red armor oil
• 25.4 cc professional-grade 2 stroke engine
• Weed trimmer features a 25.4cc professional-grade 2-stroke engine
• 2:1 gear reduction creates 28% more torque than SRM-2620
• Weed wacker comes with a 5-year consumer/2-year commercial warranty
• 2-stage air filtration system dramatically increases cleaning capability and allows for longer maintenance intervals
• Speed-Feed 400 trimmer head reloads in seconds without tools or disassembly
• 17 in. cutting swath
• Revolutionary combination of low weight and high horsepower and high torque
• Large 20.6 fl. oz. fuel tank for extended run time between fill-ups
• Tool-less access for convenient in-field servicing
• Bump automatic line advance system requires no tools
• Light 12.5 lbs. dry weight reduces fatigue
• Over-molded front and rear hand grips for comfort
• California residentssee Prop 65 WARNINGS

Dimensions

Assembled Depth (in.)	70.8 in	Assembled Height (in.)	13.2 in
Assembled Width (in.)	10.7 in	Line Style Size	.095
Maximum Cutting Path Diameter (in.)	17 in	Recommended Line Diameter (in.)	.095
Shaft Length (in.)	59 in

Details

Assembly Required	No	CA (CARB) Compliant	CARB Compliant
Engine Cycles	2 Cycle	Engine Displacement (cc)	25.4
Engine Type	2-Stroke	Features	Antivibration, Translucent Fuel Tank
Fuel Tank Capacity (oz.)	20.6 oz	Head Type	Wind without Assembly
Included	No Additional Items Included	Line Advance System	Bump
Number of Trim Lines	2	Power Type	Gas
Product Weight (lb.)	12.5 lb	Refurbished	No
Trimmer Type	Walk Behind	Shaft Type	Straight
Start Type	Manual	Tools Included	No Additional Tool
Trimmer Line Type	String

Warranty / Certifications

Manufacturer Warranty	5-year consumer / 2-year commercial

Manuals and Support

• Warranty
• Replacement Part List
• Service and Repairs
• Use and Care Manual
