Siemens SN 200 -Amp 20 -Spaces 40 -Circuit Outdoor Main breaker Plug-On Neutral Load Center
Original price was: $219.00.$190.53Current price is: $190.53.
- Manufacturer Color/Finish: Gray
- Series Name: SN
- Type: Main breaker
- Depth (Inches): 4.88
- Height (Inches): 27
- Width (Inches): 14.25
Free shipping on $25+ orders
Estimated Delivery: 5-10 days -
Pickup not available
Siemens SN 200 -Amp 20 -Spaces 40 -Circuit Outdoor Main breaker Plug-On Neutral Load Center
The new Siemens SN series plug-on neutral load center is the smart choice when value and quick installation are of highest priority. The SN series load centers include labor saving features such as the ability to accept plug-on neutral breakers, patented insta-wire and mounting trim tabs. These exclusive features make the SN series load center the best load center for the value minded contractor.
Highlights
- SN series load center includes one factory installed ground bar
- Plug-on neutral, for quick and simple breaker installation
- Aluminum bus
- Spacious with over 4 inches of wire bending space
- Secure sturdy hook-rail provides a reliable connection
- Single phase load center
- 100% Neutral and Ground positions based on number of circuits
- NEMA Type 3R outdoor enclosure
- UL Listed
Specifications
| General | |||
|---|---|---|---|
| Manufacturer Color/Finish | Gray | Type | Main breaker |
| Series Name | SN | ||
| Dimensions | |||
|---|---|---|---|
| Depth (Inches) | 4.88 | Width (Inches) | 14.25 |
| Height (Inches) | 27 | ||
| Features | |||
|---|---|---|---|
| Amperage | 200 | Orientation | Over/Under |
| Buss Bar Construction | Aluminum | Paintable | Yes |
| Circuits | 40 | Phase Type | Single phase (120/240) |
| Cover Included | Yes | Plug-On Neutral | Yes |
| Feed-Through Lugs | No | Usage | Service entrance |
| Ground Bar Installed | Yes | Use Location | Outdoor |
| Mounting Type | Combination | Value Pack | No |
| Number of Spaces | 20 | Voltage | 120 |
| Compatibility | |||
|---|---|---|---|
| Brand/Model Compatibility | Siemens | ||
| Certifications | |||
|---|---|---|---|
| CA Residents: Prop 65 Warning(s) | No | Safety Listing | UL safety listing |
| Miscellaneous | |||
|---|---|---|---|
| UNSPSC | 39121100 | ||
| Brand |
|---|
